2.5" SATA SSD
Samsung MZ-77E500BW SSD 2.5″: 500GB 870 EVO, SATA III 6 Gbps, Read/Write up to 560MB/s/530MB/s, 98K/88K IOPS, 300TBW
Availability:
5 in stock
$105.00
5 in stock
| Weight | 0.5 kg |
|---|---|
| Dimensions | 12 × 10 × 2 cm |
| Brand | Samsung |
Specifications:
| General Feature | |
| Application | Client PCs |
| Rated Capacity
|
500 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Form Factor | 2.5 inch |
| Interface
|
SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
| Dimension (WxHxD) | 100 X 69.85 X 6.8 (mm) |
| Weight | Apporx. 45.0g Weight |
| Storage Memory | Samsung V-NAND 3bit MLC |
| Controller | Samsung MKX Controller |
| Cache Memory | Samsung 512MB Low Power DDR4 SDRAM |
| Special Feature | |
| TRIM Support | TRIM Supported |
| S.M.A.R.T Support | S.M.A.R.T Supported |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| Encryption Support
|
AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive) |
| WWN Support | World Wide Name supported |
| Device Sleep Mode Support | Yes |
| Performance | |
| Sequential Read
|
Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration |
| Sequential Write
|
Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Read (4KB, QD32)
|
Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Write (4KB, QD32)
|
Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Read (4KB, QD1)
|
Up to 13,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Random Write (4KB, QD1)
|
Up to 36,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated |
| Environment | |
| Average Power Consumption (system level)
|
Average: 2.2 W *Maximum: 3.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
| Power consumption (Idle)
|
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration |
| Allowable Voltage | 5V (~ 5% Allowable voltage) |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Operating Temperature | 0 – 70 C Operating Temperature |
| Shock | 1,500 G & 0.5 ms (Half sine) |
| Accessories | |
| Installation Kit | Not Available |
| Software | |
| Management SW
|
Magician Software for SSD management, Data Migration Software for SSD upgrade |
